Applicable Industries :Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction works , Advertising Company
dimension(l*w*h) :460*450*480mm
Certification :CE
Warranty of core components :1 Year
Condition :New
Place of Origin :Guangdong, China
Showroom Location :None
Brand Name :Robotsung
warranty :1 Year
After Warranty Service :Online support
Type :Gluing Machine
MOQ :1 set
voltage :220V / 50Hz
machinery test report :Provided
Contact Now
High precision adhesive dispenser glue machine mobile phone touch screen frame glue machine
Application:
Glue Dispensing Robot is widely used in the industrial production, such as PCB Board,speaker,MP3,MP4,LCD Display,integrated circuits, printed circuit boards, electronic components, automotive parts, handbag, packing box etc.
Glue Types:
Silica gel, EMI conductive adhesive, UV glue, AB glue, glue, epoxy adhesive, sealant, hot glue, grease, glue, red glue, silver paste, thermal paste, solder paste, transparent paint, etc.
Specifications:
Model
YS-D331E
Working area
300*300*100mm
Max. speed
500mm/sec
Resolution ratio
0.01mm
Repeatability
±0.01mm
Power
250W
Voltage
220V/110v 50-60Hz
Size
460*450*480mm
Weight
90KG
Operation environment
Temperature:5-40 degrees Celsius
Humidity:20-90%RH
Customized
YES
Features:
1 English panel, easy operation.
2.Glue Dispenser Function: Drawing point, line, surface, arc, circle, irregular curve continuous complement and triaxial linkage.
3. Can set glue size, glue speed, dispensing time, stopping glue time. Stable glue exudation without glue leaking and dripping.
4. Satisfy high quality glue dispensing by adjusting the parameters of screw
5. Precise stepper motor, numerical control available
6. Applied to fluid dispensing, e. G.: UV glue, AB glue, EPOXY(black glue), white glue, EMI conductive glue, silicon, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, screw fixative...
7.According to the production process, work platform can be installed with positioning PIN, glue guns, baseboard heating temperature controlling device.
